Envstation
The product description
-
Brief specifications:
-
Function and application scenario description:
A high-precision & low-power real-time data acquisition and detection IoT workstation which enables the end-to-end communication security solution to the Microsoft Azure Sphere cloud with an embedded IoT security chip for the data center.
-
Specifications:
- Microsoft Azure Sphere IoT architecture
- MT3620AN
- 2G flash memory
- Dual power supply
- 6 AC voltage real-time detection
- Northbound link
- - Dual Band (2.4GHz & 5GHz) Wi-Fi
- 10BASE-T W5500 Ethernet
- Temperature/Humidity sensor
- In case/On board Temp/RH detection
- Particulate sensor
- Particle level measurement
- Accelerometer sensor
- x/y/z 3-axis detection
- WGBT/HSI sensor
- Pressure measurement
- Chassis dimensions
- - 863.6mm× 441.0mm× 43.3mm
- Secure firmware updates
- Certifications
- - FCC
- - CE
- - ETL
- - RoHS
- RJ45: For Northbound Ethernet
- 4 digits 8 segments LED
- USB Type-B Port
- 3 * RS485
- 4 * GPIO
- Voltage acquisition * 6
